System weight: 25 - 27 kg. The maximum height of the system is between 2500 and 3000
mm. (Outdoor: 2500 mm, Indoor 3000mm)
System wing width is maximum 1800 mm. (Each wing should not exceed 4m2)
Glasses are 8 - 10 mm tempered. It can also be made as 4 mm tempered + 12 mm air gap
+ 4 mm tempered.
Since the wings are not folded in, any kind of curtain can be applied.
The wings carry each other thanks to the special pulling apparatus.
The system must carry from below, the threshold height is 40 mm.
The system is suitable for working in any type of balance environment thanks to
adjustable lower wheels.
Thanks to the corner wedges, it provides mounting advantage without any loss in
aluminum.
It can be applied on all kinds of rotating balconies. (Except Oval Balconies)
The glasses are fixed with aluminum gasket thanks to the special gasket. Silicone is not
used.
