All aluminum carriers are made of 100x100 special aluminum profiles, back
columns and engine platform 100x000.
Rail Profile consists of 70x150 special aluminum profiles.
The system can be easily adapted to any angle with the connection elements
(“Joint” and Aluminum “L”) that combine the Rail Profiles and the Carrier.
M8 screws and special lock nuts used in the assembly are stainless.
The system works with a slope of 15%.
The maximum possible distance between the Upper Rail Profiles is 400 cm.
Lighting LED is used.
Canvas fabric is PVC Based, 780gr/m² in weight. It has three-layer blackout
(lightproof), waterproof, non-flammable, flameproof (CL2-UNI EN 13773)
features.
